Printed in Germany • Edition 02.14 • Nr. 254 722
10 Error overview
MPA 51xx
Error
ID
Internal
error
Error description Possible cause of the error
0x4C
ERROR_PARAMETER_RECORD_STICK_
BLOCK_ADJUSTMENT
? A parameter could not be copied from
the stick, for ex. because the variable lim-
its in the MPA were conned.
0x4d
ERROR_PARAMETER_RECORD_STICK_IN-
CORRECT_PASSWORD
? The entered password is not suitable for
this stick
0x4E
ERROR_PARAMETER_RECORD_STICK_
NO_CONTINUOUS_RUN
? Duration of the standard mode (P70) is
higher than 23 h 59 min and the continu-
ous run is not enabled
0x4F
ERROR_PARAMETER_RECORD_STICK_
TYPE
? The stick does not t with the type of au-
tomatic burner control
0x50 ● ERROR_FEEDBACK_ADDITION_INCORRECT
0x51
ERROR_ADDITION_INVALID_DELAY ? Parameter P52 or P53 are set to an
invalid value because the concerned state
(P50 or P51) cannot have the set duration
0x52 not used
0x53 ERROR_LACKOFGAS_GDWVPS
0x54 ●
ERROR_PWM_CALIBRATION_VALUES ? The EEPROM was changed or deleted
when programming the parameter record
stick
? Parameter record stick defective
0x55 ●
ERROR_PARAMETER_RECORD_STICK_
CRC_DATA
? Parameter record stick defective
... not used
10.4 Error from the application (from 0xA0)
0xA0
ERROR_STATE_DURATION_TOO_LONG
(Error fan and/or stepped motor)
? in the state 3, 16 and 23: The fan and/or
the stepped motor cannot reach its nomi-
nal value within the expected time period
? other states: Internal error
0x A1
ERROR_FAN_STARTUP
(Error fan and/or stepped motor)
? in the state 3, 16 and 23: The fan and/or
the stepped motor cannot reach its nomi-
nal value within the expected time period
? other states: Internal error
0xA2
ERROR_SAFETY_CHAIN_OPEN ? The safety chain has been opened or is
not closed
? The wires of the safety chain are inter-
rupted
0xA3
ERROR_PARAMETER_RECORD_STICK_
NO_PASSWORD
? The values in the MPA and in the param-
eter record stick are dierent. The request-
ed password was not entered (timeout).
0xA4 ● ERROR_FEEDBACK_V1_INCORRECT
0xA5 ● ERROR_FEEDBACK_V2_INCORRECT
0xA6
ERROR_EXTERNAL_LIGHT ? Earth connection to an ionisation elec-
trode
? Gas ows out and is burned for ex. by
neighbouring burners
? Connected ame detector detects ex-
ternal light
