Duplo DBM-150T User Manual

1-7
Chapter 1 Before Operation
No. Name Function
[1] Side guide Aligns the sides of paper.
(p.2-12)
When the SXS MODIFICATION KIT (option) is attached to this
machine, the shape of the side guide is dierent.
(p.3-4)
[2] Conveyance roller Conveys paper.
(p.4-1)
When the SXS MODIFICATION KIT (option) is attached to this
machine, there is no conveyance roller.
[3] Conveyance belt Conveys paper.
(p.4-1)
[4] Back guide Aligns the trail edge of paper and conveys paper.
(p.2-12)
[5] Stopper Decides the stapling position and folding position.
[6] Clincher Bends the stapler pin at.
(p.2-5)
[7] Clincher xing screw Loosen the screw when moving the clincher.
(p.2-5)
[8] Hexagonal wrench holder Holder for storing the supplied hexagonal wrench
(p.2-5)
[9] Roller gap adjustment Adjusts the gap between the folding rollers.
(p.2-10)
[10] Ejection unit Ejects a booklet folded by the folding rollers. When a paper jam
has occurred, remove the ejection unit to remove the paper.
(p.5-5)
[11] Folding roller Fold a booklet.
(p.2-10)
[12] Inlet for stapler unit connector Connector for the stapler unit.
(p.2-5)
[13] Stapler xing knob Fastens the stapler unit.
(p.2-5)
[14] Stapler unit F Staples a bunch of paper. This is attached to the operator’s side of
the machine.
(p.2-5)
[15] Stapler unit B Staples a bunch of paper. This is attached to the non-operator’s
side of the machine.
(p.2-5)
