Duplo DBM-150T User Manual

1-8
Chapter 1 Before Operation
2-3. DBM-150T
[1]
[5]
[5]
[4]
[6]
[7]
[7]
[6]
[6]
[3]
[2]
No. Name Function
[1] Top cover Cover for ensuring user safety. This machine will not operate if
open.
[2] Scrap box Scrap paper of trimmed booklets is ejected to this box.
[3] Trimming stopper adjustment Adjusts the position of the trimming stopper to correct trimming
misalignment.
(p.2-19)
[4] Roller gap adjustment lever Adjusts the gap between the conveyance rollers. Adjustable to two
positions.
(p.2-18)
[5] Conveyance belt Conveys paper.
(p.4-1)
[6] Paper holder Holds paper during trimming.
[7] Trimming position stopper Determines the length of the paper.
(p.2-19)

Duplo DBM-150T Specifications

General

Brand	Duplo
Model	DBM-150T
Category	Trimmer
Language	English
