Chapter 5 Trouble Guide
Condition Cause Solution
The stapling positions
vary depending on a
booklet.
Stapling is performed when sheets are not
aligned with each other.
Select [No. of Jogs] from the function
menu on the control panel and increase
the value.
(p.1-15)
The back guides are not properly adjusted. Select [Back Guide] from the ne
adjustment menu on the control panel
and narrow the distance between the back
guides.
(p.1-17)
The stapling positions are
dierent at between the
operator’s side and the
non-operator’s side.
The attachment position of the stapler
unit is not appropriate.
Check the attachment position of the
stapler unit.
(p.2-5)
The folding misalignment
occurs.
The folding misalignment is not adjusted. Adjust the folding misalignment using the
folding misalignment adjustment.
(p.2-17)
The position of the back guides is not
appropriate.
Select [Back Guide] from the ne
adjustment menu on the control panel and
adjust the position of the back guides.
(p.1-17)
The position of the side guides is not
appropriate.
Select [Side Guide] from the ne
adjustment menu on the control panel and
adjust the position of the side guides.
(p.1-17)
The position of the roller gap adjustment
is dierent between at the operator’s side
and the non-operator’s side.
Move the roller gap adjustment to the
same position at the both side.
(p.2-10)
Even after adjusting
folding misalignment, the
folding position varies
depending on a booklet.
The folding operation starts early. Select [Fold Start T] from the ne
adjustment menu on the control panel and
increase the value.
(p.1-17)
Even after adjusting
folding misalignment and
increasing the folding
start timing, the folding
position varies depending
on a booklet.
The position of the back guides is not
appropriate.
Select [Back Guide] from the ne
adjustment menu on the control panel and
adjust the position of the back guides.
(p.1-17)
There is a scratch on the
booklet surface.
The gap between the folding roller is too
narrow
Widen the folding roller gap using the
roller gap adjustment.
(p.2-10)
Booklets are not smoothly
ejected.
The folding roller gap is too wide for the
booklet thickness.
Narrow the folding roller gap using the
roller gap adjustment.
(p.2-10)
The ejection unit has not been attached to
the machine.
Attach the ejection unit to the machine.
(p.5-4)
After turning on the
upstream unit, the DBM-
150 is not turned on.
The settings of the power switch and the
main power switch of the DBM-150 are
wrong.
Check if the power switch and the main
power switch of the DBM-150 are correctly
set.
(p.2-1)
Pressing the key
do not start binding
operations.
When the upstream unit is connected to
the DBM-150, the key of the DBM-150
is pressed.
Press the start key of the upstream unit.
The error is displayed on the LCD display. Clear the error.
(p.5-1)
Pressing the key
does not display the
setting menu.
The sheet feeder or the DFC-100 is
connected to the DBM-150 as the
upstream unit.
Make setting for each item of the setting
menu in the upstream unit or the PC
CONTROLLER.
Pressing the F key does
not display the function
menu. Or only the buzzer
setting menu is displayed.
The sheet feeder is connected to the DBM-
150 as the upstream unit.
Make setting for each item in the function
menu in the upstream unit or the PC
CONTROLLER.
