Programming a New JOB (Advanced Mode)
39
Programming JOB on Control Panel
2
Air knife (Optional on 230V Asia model)
Use the CURSOR (Right) or (Left) key to turn ON/OFF the Air
knife, and press the SET key or the CURSOR (Down) key.
Turn ON this function when processing document with excessive
static electricity or heavy weight document.
REFERENCE
Read REG mark (Optional on 115V model and 230V Asia model)
Use the CURSOR (Right) or (Left) key to turn ON/OFF the Read
REG mark (REG mark reading), and press the SET key or the
CURSOR (Down) key.
IMPORTANT
It is not possible to turn ON this function if either the Lead
mark or Side mark does not have a value entry (i.e. if the
value entry is 0 mm). To turn ON this function, enter an value of
Lead mark and Side mark. (See steps 14 and 15).
Suction power
Use the CURSOR (Right) or (Left) key to select MAX, MID, or MIN,
and press the SET key or the CURSOR (Down) key.
(0/***.*-***.*)
***.*mm
Crease20
Enter the value for Crease2 to Crease20 in a similar way to step
20.
When each input is complete, press the SET key.
When you require fewer than 20 creases, enter 0 after the last
crease setting and then press the SET key or the CURSOR (Down)
key.
JOB** entry
(0/***.*-***.*)
***.*mm
Perf 1
JOB** entry
(0/***.*-***.*)
***.*mm
Perf 2
JOB** entry
Air knife
ON OFF
JOB** entry
JOB** entry
Suction power
MAX MID MIN
Read REG mark
ON OFF
JOB** entry
Perforation 1 (Optional on 115V model and 230V Asia model)
Enter the distance from the right edge of the document to the fi rst
processing position. (right side)
When input is complete, press the SET key or the CURSOR (Down)
key.
Perforation 2 (Optional on 115V model and 230V Asia model)
Enter the distance from the right edge of the document to the
second processing position (left side).
When input is complete, press the SET key or the CURSOR (Down)
key.
To Next Page
