18
7. OPERATION PROCEDURES
2 Adjust the stopper of second folding plate.
1 While lifting the rough adjustment knob of second folding plate, slide it to the ''Press" position shown in the figure
and set it there.
2 Rotate the fine adjustment knob to the left until the rough adjustment knob presses against it lightly but completely.
Note : Rotating the fine adjustment knob excessively will result in paper jamming, improper folding, and other
mechanical malfunctions.
3 Start folding operations hereafter using the normal procedure.
If the above problem occurs, it means that the stopping position of the stopper is too apart. Rotate the fine adjustment knob to
the left until the folding stopper lightly but completely presses against it.
WHAT TO DO WHEN :
When single-folding paper, if the folding stopper (rough adjustment knob) of second folding plate is not at the correct
position, the following problems may occur according to the type of paper used (thickness, paper quality, etc.)
If the paper is thin (no hardness) ........ A crease about 0.59 inch from the folded line of the paper parallel to it will be formed.
Rough adjustment knob
