3. INSTALLING THE UNIT
After checking that you have following parts, attach them to the unit.
3-2. COMPONENT PARTS
No.
Name
Qty. No.
Name
Qty.
First folding plate
Second folding plate
Cross folding lever
Instruction Manual
Guide plate unit
1
2
3
4
5
1
1
1
1
1
12
3
54
3-3. BEARING SUPPORT LEVERS
Bearing support lever
Bearing support lever
Support the bearing with the two bearing support levers.
• Rotate the lever in the arrow direction and support the bearing.
<Operating side>
<Non-operating side>

Duplo DF-505N Specifications

General

Brand	Duplo
Model	DF-505N
Category	Folding Machines
Language	English
