37
11 From here, refer to “7. Operation
Procedures”.
• When replenishing paper, raise the cross folding
lever as shown in the figure first.
Cross folding consists of not only the single
folding of LD, double folding of LT, but the
letter folding of LT.
12 After use, store the cross folding
lever as shown in the figure.
10-3. CROSS FOLDING OF NON-FIXED PAPER
• The following describes the
procedures for single cross folding.
• Start single cross folding of non-fixed
paper according to the following
procedure.
1 Adjust the rough adjustment knob of
first folding plate to the mark which
has a value half of this length.
• Adjust the rough adjustment knob of the second
folding plate to “End”.
Cross folding lever
Rough adjustment knob Rough adjustment knob
Second folding plate First folding plate
10. CROSS FOLDING (Optional-Cross Folding kit is required)
To Next Page
