22
To use the reversal mechanism, select the reversal mechanism. Refer to “9-1. Selecting the
Reversal Mechanism”.
4
6. OPERATIONS
w Turn the jog dial to display “Staple/Fold Mode”, and press the jog dial to confirm the setting.
“Trimming Mode” cannot be set.
Set the “Staple/Fold Mode” as follows on the left edge, and press the jog
dial to confirm.
To perform folding : “Fold”
To perform saddle-stapling and folding: “Booklet”
To perform side-stapling : “Side ST” (Valid only when the paper size is set to “Custom Size”)
To perform corner-stapling : “Corn.ST” (Valid only when the paper size is set to “Custom Size”)
NOTE : “Through” cannot be set. And “Side ST” and “Corn.ST” cannot be set if the DBM-400T is
connected.
This setting will not change even if the power is turned off and turned on again.
Adjust the downstream processing unit at the downstream processing unit side.
(3) Selecting and setting the paper feeder B
Refer to “7-1. Using the Paper Feeder B”.
NOTE : This setting will not change even if the power is turned off and turned on again.
Staple/Fold Mode
Booklet
Select Job
Through Fold Bo
When connecting the DBM-400 Sheet by Sheet
q Turn the jog dial at the initial screen to display the “Finisher Mode”, and press the jog dial to confirm the setting.
To use the end mark detection function, set the end mark detection function. Refer to “8-2.
Setting the End Mark Detection Function”.
3
