PC Controller Setting
4
Programming a JOB on a Computer
Pattern 2
X2-R
Pattern 1
X1-R
Pattern 1
X1-L
Pattern 2
X2-L
Start End
Set 1
Set 1
Set 1
Set 1
Set 2
Set 2
Set 2
Set 2
Set 3
Set 3
Set 3
Set 3
Set 4
Set 4
Set 4
Set 4
Set 5
Set 5
Set 5
Set 5
Set 6
Set 6
Set 6
Set 6
● Patterns of processing with the
RTM (Rotary Tool Module)
You can program up to six sets in the Y direction of Pattern X1.
You can program up to six sets in the Y direction of Pattern X2 as well.
Document
feed
direction
