Dynalink DL-WRX36 User Manual

7. FAQ
120
What is MU-MIMO?
MU-MIMO, stands for Multi-User, Multiple Input and Multiple Output technology. MU-MIMO enables the communication with multiple devices
simultaneously. More connected devices, No more waiting, and no more slow-connection.
In 802.11n(WiFi 4), multiple spatial streams can transmit to a single client at one time. It is also called Single-User MIMO (SU-MIMO).
In 802.11ax(WiFi 6) and 11ac(WiFi 5), MU-MIMO are introduced. Router or AP can transmit to multiple clients at the same time.
How to reset DL-WRX36 router to factory default settings?
A factory reset will restore all the settings to default status just like you firstly got the router. Make sure you have already backed up the configuration
before using the process of reset to default to fix other issues. Factory reset could be done via the reset button on the back side of the router (See
in the user guide 3. Installation for the location of each interface). Press and hold the button for 7 seconds. You will see the power LED starts
flashing blue and then lights off in a few seconds. After that, the router will reboot automatically. You can see all the configurations become default
status when the process is completed. In another way, you can also reset the router to default via Web UI or APP. Go to System Settings >
Configuration & Reset and click the Reset to Default button. The router will automatically start the factory reset process.
What if I forgot my login password?
If you forget the login password, please refer to the product label which is located on the bottom of the router. You will see the username,
password, and other detailed information. Use the default password to access the web UI. However, if you changed the default password
previously, you will need to reset the router to default
if you changed the default password previously, you will need to reset the router to default. Otherwise, you can refer to the product label which is
located on the bottom of the router. You will see the username, password, and other detailed information.

Dynalink DL-WRX36 Specifications

System Memory

flash memory	256 MB
RAM	1 GB DDR4

Ports & Interfaces

wireless interface	2.4GHz and 5GHz Dual-Band Concurrent
LAN ports	4 Gigabit LAN Port
WAN port	One 2.5 Gigabit WAN Port

Wireless Specifications

wireless standard	IEEE802.11a/b/g/n/ac/ax
frequency range 2.4 GHz	2.412 GHz ~ 2.4835 GHz
frequency range 5 GHz	5.15 GHz ~ 5.35 GHz, 5.47 GHz ~ 5.85 GHz

Antenna

antenna for 2.4 GHz	4-internal
antenna for 5 GHz	4-internal
maximum output power 2.4 GHz	29 dBm
maximum output power 5 GHz	29 dBm

Power

operating voltage	12V/2.5A DC adaptor (100V~240V, 50 Hz ~ 60 Hz)
maximum power consumption	26.8 Watts

Operating Environment

operating temperature	0°C ~ 40°C
storage temperature	-40°C ~ 85°C
operating humidity	5% ~ 90% RH
storage humidity	5% ~ 95% RH

Weight and Dimensions

width	100 mm
height	230.25 mm
depth	150 mm
