Dynatone DPR-3500 - Assembly

6
1
Assembling the legs and pedals
Attaching the backplate
2
1 Place the backplate (d) between the
legs by inserting it from behind.
2 Use the backplate fixer (f), (g) to fix the
backplate (d).
3 Make sure that the plate is standing
straight.

B
C
D
F
F
E
G
H
H
"
$
.
1

.
6
4
*
$
Assembly
1 Set the legs (a, b) upside down like the
picture, then use 4 Pedal Plate/Main Body
Fixers (e, use 4 out of 10) to connect the
Pedal Plate (c) to the legs.
2 Adjust the pedal plate knob (see picture)
so that it would come in contact with the floor
on which the piano is to be installed.

F
Assembly
