HIGH PRESSURE BLOWER INSTALLATION
Model 200i/250i Above Ground Blower Installation
Version 4 High Pressure Blower Installation Guide
Figure 3: Install the High Pressure Blowers—Above Ground
blower assembly
1/8-inch thick
poly washer
motor
facing out
intake facing in
1/4-inch thick
poly washer
upper blower
arm assembly
power cord
from blower
lower arm has
longer pin
power source on
dyno chassis
1/8-inch thick
poly washer
3/4-inch
clamp lever
1.5-inch
clamp lever
