High Pressure Blower Installation Guide
H
IGH
P
RESSURE
B
LOWER
I
NSTALLATION
This document provides instructions for installing the high pressure blower
assemblies to the motorcycle dynamometer (dyno) including instructions for
installing the stand alone blower assembly. Appendix B includes instructions for
installing the high pressure blower assemblies to the model 200/250 dyno while
Appendix C includes instructions for installing the high pressure blower to the model
200iX/250iX dyno. To ensure safety and accuracy in the procedures, perform the
procedures as they are described.
Document Part Number: 98220105
Version 4
Last Updated: 03-11-2020
This chapter is divided into the following categories:
• Introduction, page 2
•Main Dyno Power, page 3
• Model 200i/250i Above Ground Blower Installation, page 5
• Model 200i/250i In Ground Blower Installation, page 8
• Stand Alone Blower Installation, page 13
