Dyson DC15 Service Manual

service manual
Issued 05/05
12
Fitting notes
Lift the front edge of the soleplate off the
brush housing. Then unclip from the rear.
Lift the glamour cover out of the rear of
the brush housing.
Slide out the brushbar motor front mount
from the front of the brush housing.
Lift the four soleplate wheels and axles out
of the underside of the brush housing. Slide the
wheels off the axles.
Release both bumper catches from the
front of the brush housing using a Torx
screwdriver.
34
35
36
33
32
Firmly push the bumper and bumper
rubber off the front of the brush housing.
37

Dyson DC15 Specifications

General

Type	Upright
Ball Technology	Yes
Cord Length	35 ft
Filter Type	HEPA
Filter	Lifetime HEPA
Special Features	Ball technology
Cyclone Technology	Root Cyclone™ technology
