Operation
Eaton 9130 700/3000 VA UPS User’s Guide 164201718—Rev 7 www.eaton.com/powerquality 27
Changing the Language
Press and hold the first button on the left for approximately three seconds to select the language menu. This
action is possible from any LCD menu screen.
Display Functions
As the default or after 15 minutes of inactivity, the LCD displays the start screen.
The backlit LCD automatically dims after 15 minutes of inactivity. Press any button to restore the screen.
Press any button to activate the menu options. Use the two middle buttons ( and ) to scroll through the menu
structure. Press the Enter (
) button to select an option. Press the
button to cancel or return to the
previous menu.
Table 2 shows the basic menu structure.
Table 2. Menu Map for Display Functions
Main Menu Submenu Display Information or Menu Function
UPS Status Main status (mode and load) / Notice or Alarm sta
tus (if any) / Battery
status (state and charge level)
Event Log Displays up to 127 events and alarms
The Event Log is also available through the
serial port. See ”Retrieving the
Event Log”on page 33.
Measurements Load W VA / Load A pf / Output V Hz / Input V Hz / Bypass V H
z / Input Line
Events / Battery V min
Control Go to Bypass Transfers the UPS system to internal Bypass mode
When this command is active, the option changes to “Go
to Normal.”
Start Battery Test Starts a manual battery test
See ”Testing New Batteries”on pag
e 52.
Reset Error State Clears a “Battery Test Failed”alarm
Load Segments Load segment 1: ON | OFF
Load segment 2: ON | OFF
These commands overrule user settings
for load segments. See
“Configuring Load Segments”on page 35.
Restore Factory Settings Returns all settings to original values only after UPS
is powered down.
The following settings do not change:
"Output voltage setting
"Site wiring fault alarm
"REPO terminal setting
"Serial number
"Part number
Identification UPS Type / Part Number / Serial Number / Firmware
Settings User Settings See Table 3 for details.
Service Settings This menu is password-protected.
To Next Page
