UPS Initial Startup
To start up the UPS:
NOTE Verify that the total equipment ratings do not exceed the UPS capacity to prevent an
overload alarm.
1. Verify that the internal batteries are connected.
Rack models. See
“Installing the UPS” on page 16.
To w e r m o d e l s .
See “Installing the UPS” on page 21.
2. If optional EBMs are installed, verify that the EBMs are connected to the UPS.
Rack models. See “Connecting the EBM(s)” on page 18.
To w e r m o d e l s .
See “Connecting the EBM(s)” on page 22.
3. Plug the equipment to be protected into the UPS
, but do not turn on the protected equipment.
4. Make any necessary provisions for cord retention and strain
relief.
5. M
odels without an attached power cord. Plug the detachable UPS power cord into the input connector
on the UPS rear panel.
6. Plug the UPS power cord into a power outlet.
The UPS front panel display illuminates and sho
ws a status of “UPS initializing…”
7. Verify that the UPS transfers to Standby mode (“UPS on standby”).
8. Press the
button on the UPS front panel for at least one second.
The UPS front panel display changes
status to “UPS starting…”
9. Check the UPS front panel display for active alarms or
notices. Resolve any active alarms before
continuing. See “Troubleshooting” on page 83.
If the
indicator is on, do not proceed until all alarms are clear. Check the UPS status from the front
panel to view the active alarms. Correct the alarms and restart if necessary.
10. Verify that the
indicator illuminates solid, indicating that the UPS is operating normally and any loads
are powered.
The UPS should be in Normal mode.
11. Press the
button until the start screen appears.
12. If optional EBMs are installed, see “Con
figuring the UPS for EBMs” on page 36 to set the number of
installed EBMs.
13. To change any other factory-set defaults, see Table 3 on page 28.
NOTE Eaton recommends setting the date and time.
NOTE At initial startup, the UPS sets system frequency according to input line frequency
(input frequency auto-sensing is enabled by default). After initial startup,
auto-sensing is disabled until manually re-enabled by output frequency setting.
