User Settings
The following table displays the options that can be changed by the user.
Table 3. User Settings
Description Available Settings Default Setting
Change Language [English] [French] [Spanish] [German] [Russian]
Menus, status, notices, and alarms are in all
supported languages. UPS faults, Event Log data,
and settings are in English only.
English
User Password [Enabled] [Disabled]
If Enabled is selected, the password is USER.
Disabled
Audible Alarms [Enabled] [Disabled] Enabled
Set Date and Time
NOTE Time is a 24-hour clock.
Set Year, Month, Day, Hours, Minutes
Date: yyyy/mm/dd
Time: hh:mm
2008/01/01
12:00
Signal Inputs ** Setup: [Not Used] [Force Bypass]
[Remote
Shutdown] [Delayed Shutdown]
[On
Generator] [Building Alarm 1]
Active: [High] [Low]
See ”Programmable Signal Inputs”on page 42.
RS232-3: Not Used, High
cXSlot Serial: Delayed
Shutdown, High
cXSlot Signal: Remote Shutdown,
Low
Relay Configuration ** [UPS ok] [On Bypass] [On Battery] [Battery Low]
[Ext. Charger On]
See “Relay Output Contacts”on page 41.
Standard: UPS ok
RS232-1: Battery Low
RS232-8: On Battery
cXSlot-K1: On Battery
cXSlot-K2: Battery Low
cXSlot-K3: UPS ok
cXSlot-K4: On Bypass
Serial Port Configuration [1200 bps] [2400 bps] [9600 bps]
USB communication requires 9600 bps.
RS232: 9600 bps
cXSlot: 9600 bps
Control Commands from Serial Port [Enabled] [Disabled] RS232: Enabled
cXSlot: Enabled
Output Voltage
NOTE The UPS must be in Standby
Mode when you change the
output voltage.
[100V] [110V] [120V] [127V] [Autosensing]
[200V] [208V] [220V] [230V] [240V] [Autosensing]
120V (low voltage models)
230V (high voltage models)
Output Frequency
NOTE The UPS must be in Standby
Mode when you change the
output frequency.
[50Hz] [60Hz] [Autosensing] Autosensing
Frequency Converter [Enabled] [Disabled]
If Enabled, the UPS operates as a frequency
converter, with bypass operation and all
bypass-related alarms disabled.
Disabled
NOTE * See “Configuring Bypass Settings”on page 34.
NOTE ** The cXSlot Signal setting is for a communication card. The cXSlot Serial setting is for the relay card.
