Eaton 9130 700/3000 VA UPS User’s Guide 164201718—Rev 7 www.eaton.com/powerquality 83
Chapter 8 Troubleshooting
The Eaton 9130 is designed for durable, automatic operation and also alerts you whenever potential operating
problems may occur. Usually the alarms shown by the control panel do not mean that the output power is
affected. Instead, they are preventive alarms intended to alert the user.
In general:
l
Events are silent conditions that are recorded in the Event Log as status information, such as “Clock Set
Done.”
l
Notices are announced by a beep every five seconds, recorded in the Event Log, and displayed on the LCD.
Examples are “UPS on Battery” and “UPS on Bypass.”
l
Alarms are announced by a beep every second, recorded in the Event Log, displayed on the LCD, and the
Alarm indicator illuminates. Examples are “Output Overload” and “Heatsink Overtemperature.”
Use the following troubleshooting chart to determine the UPS alarm condition.
Typical Alarms and Conditions
To check the UPS Status menu for a list of active alarms:
1. Press any button on the front panel display to activate the menu options.
2. Press the
button until UPS STATUS displays.
3. Press the Enter button to display the list of active alarms.
To check the Event Log for a history of conditions:
1. Press any button on the front panel display to activate the menu options.
2. Press the
button until EVENT LOG displays.
3. Press the Enter button to display the list of conditions.
You can also retrieve the entire Event Log in ASCII format. See “Retrieving the Event Log” on page 33.
The following table describes typical alarms and conditions.
Table 31. Typical Alarms and Conditions
Alarm or Condition
Possible Cause Action
On Battery
LED is on.
1 beep every 5 seconds.
A utility failure has occurred and the
UPS
is in Battery mode.
The UPS is powering the equipment with battery power.
Prepare your equipment for shutdown.
Battery Low
LED is flashing slowly.
1 beep every second.
The UPS is in Battery mode and the
battery is ru
nning low.
This warning is approximate, and the actual time to
shutdown may vary significantly. Depending on the UPS
load and number of Extended Battery Modules (EBMs),
the “Battery Low”warning may occur before the
batteries reach 25% capacity. See Table 23 to Table 26
starting on p
age 60 for estimated runtimes.
On Bypass
LED is on.
1 beep every 5 seconds
The UPS is in Bypass mode. The equipment transferred to bypass utility power.
B
attery mode is not available and your equipment is not
protected; however, the utility power continues to be
passively filtered by the UPS. Check for one of the
following alarms: overtemperature, overload, or UPS
failure.
