Eaton 9130 - Page 88

RS-232
Port
USB
Port
Communication
Bay
REPO
Port
Relay
Port
IEC C14-10A
Input Connector
(5) Aust 10A
Output
Receptables
(4) C13
Output
Receptables
EBM
Connection
Specifications
Eaton 9130 700/3000 VA UPS User’s Guide 164201718—Rev 7 www.eaton.com/powerquality 82
Figure 59. Model PW9130G2000T-XLAU
Communication
Bay
RS-232
Port
USB
Port
REPO
Port
Relay
Port
IEC C20-16A
Input Connector
(5) Aust 10A
Output
Receptables
(1) C13
Output
Receptable
EBM
Connection
Figure 60. Model PW9130G3000T-XLAU
