Eaton 9130 - Chapter 7 Specifications; Model Lists and Communication Options

Eaton 9130 700/3000 VA UPS User’s Guide 164201718—Rev 7 www.eaton.com/powerquality 53
Chapter 7 Specifications
This chapter provides specifications for the Eaton 9130 UPS models:
l
Communication options
l
Model lists
l
Weights and dimensions
l
Electrical input and output
l
Environmental and safety
l
Battery
Table 11. Communication Options (All Models)
Communication Bay (1) available independent communication bay for connectivity cards
Compatible Connectivity Cards Network Card-MS
Relay Interface Card
Communication Ports RS-232 (DB9): 12009600 bps
USB: 9600
bps
Signal Inputs (4) programmable signal inputs (signal and signal return) for indicating building alarms or other use
Relay Output Contacts (1) three-pole connector with (1) contact closure
Table 12. Extended Battery Module Model List
EBM Model Configuration Battery Voltage For Power Ratings
PW9130N1000R-EBM2U Rackmount 36 Vdc 700–1000 VA
PW9130N1000R-EBM2US 36 Vdc 700–1000 VA
PW9130N1500R-EBM2U 48 Vdc 1500 VA
PW9130N1500R-EBM2US 48 Vdc 1500 VA
PW9130N3000R-EBM2U 72 Vdc 2000–3000 VA
PW9130N3000R-EBM2US 72 Vdc 2000–3000
VA
EBM Model Configuration Battery Voltage For Power Ratings
PW9130N1000T-EBM Tower 36 Vdc 1000 VA
PW9130N1500T-EBM 48 Vdc 1500 VA
PW9130N3000T-EBM 96 Vdc 2000–3000 VA
Table 13. UPS Model List (Rackmount Models)
Model Power Level Rear Panel Diagram
PW9130L700R-XL2U 700 VA / 630W Figure 28 on page 69
PW9130L700R-XL2US 700 VA / 630W Figure 28 on page 69
PW9130L1000R-XL2U 1000 VA / 900W Figure 28 on page 69
PW9130L1500R-XL2U 1500 VA / 1350W Figure 33 on page 70
PW9130L1500R-XL2US 1500 VA / 1350W Figure 33 on page 70
PW9130L2000R-XL2U 2000 VA / 1800W Figure 35 on page 71
PW9130L2000R-XL2US 2000 VA / 1800W Figure 35 on page 71
PW9130L2500R-XL2U 2500 VA / 2250W Figure 39 on page 72
PW9130L3000R-XL2U 3000 VA / 2700W Figure 39 on page 72
