Operation
Eaton 9130 700/3000 VA UPS User’s Guide 164201718—Rev 7 www.eaton.com/powerquality 29
Overload Alarm Level [10%] [20%] [30%]...[100%]
These values affect alarm level only, not UPS
operation such as transfers or shutdown.
100%
Generates the Output Overload
alarm at the set level.
Transfer to Bypass When Overload* [Immediate] [After Delay]
If Immediate, transfer occurs at load >102%.
If
After Delay, transfer occurs according to
Table 22 on page 59.
Immediate
Power Strategy [Normal] [High Efficiency]
See “Setting Power Strategy”on page 33.
Normal
Automatic Start Delay [Disabled] [No Delay] [1s] [2s]...[32767s]
If Disabled, automatic restart is not allowed. See
“Configuring Load Segments”on page
35.
Load Segment 1: No Delay
Load Segment 2: No Delay
Automatic on Battery Shutdown [Disabled] [No Delay] [1s] [2s]...[32767s]
Shutdown cancels if utility returns before the delay
expires. See “Configuring Load Segments”on
page
35.
Load Segment 1: Disabled
Load Segment 2: Disabled
Start on Battery
NOTE Utility must be present and
output enabled at initial UPS
startup.
[Enabled] [Disabled]
After initial startup, battery voltage must exceed
2.10
volts per cell to start on battery.
Enabled
Energy Saving Mode [Disabled] [50W] [100W]...[1000W]
UPS output is turned off if the UPS is on battery
and output power is below the selected level.
Disabled
Remote Shutdown Delay [No Delay] [1s] [2s]…[10800s] No Delay
Delayed Shutdown Delay [No Delay] [1s] [2s]…[10800s] 120s
Behavior on Rectifier Input Loss
NOTE Available only in >3000 VA
UPSs with separate supply
sources for the rectifier and
bypass inputs.
[Prefer Battery] [Prefer Bypass]
If Prefer Bypass, upon loss the UPS will transfer to
bypass in 3
seconds and remain as long as bypass
is available.
Prefer Battery
On Battery Notice Delay [0] [1s] [2s]…[99s] 5s
Site Wiring Fault Alarm [Enabled] [Disabled]
An active site wiring fault alarm prevents startup
or, if operating, forces operation to Battery mode
and disables bypass.
Enabled for L, i, and G (AU)
models (120V, 230V, and 240V)
Disabled for G and G (EU) models
(208V)
Bypass Voltage Low Limit* [-4%] [-5%] … [-20%] of nominal -15% of nominal
Bypass Voltage High Limit* [+4%] [+5%] … [+20%] of nominal +10% of nominal
Qualify Bypass* [Never] [When in Spec] [Always on UPS Fault]
[Always]
When in Spec
Synchronization Window* [Sync Disabled] [0.5 Hz] [1.0 Hz] [2.0 Hz] [3.0
Hz]
2.0 Hz
Unsynchronized Transfers* [Enabled] [Disabled] Enabled
Table 3. User Settings (Continued)
Description Available Settings Default Setting
NOTE * See “Configuring Bypass Settings”on page 34.
NOTE ** The cXSlot Signal setting is for a communication card. The cXSlot Serial setting is for the relay card.
