Specifications
Eaton 9130 700/3000 VA UPS User’s Guide 164201718—Rev 7 www.eaton.com/powerquality 68
500/350 72 225 449 590 766
PW9130G2000T-XL / PW9130G2000T-XLEU / PW9130i2000T-XL (Estimated runtimes)
2000/1400 15 61 111 156 186
1500/1050 21 81 145 184 248
1000/700 34 129 198 293 431
500/350 72 225 449 590 840
PW9130L3000T-XL
3000/2100 9 35 66 95 132
2250/1575 13 53 100 139 183
1500/1050 22 86 153 221 267
750/525 69 168 298 395 545
PW9130G3000T-XL / PW9130G3000T-XLEU / PW9130i3000T-XL (Estimated runtimes)
3000/2100 9 36 68 101 137
2250/1575 12 49 90 134 165
1500/1050 20 79 143 180 240
750/525 46 161 267 434
547
NOTE Battery times are approximate and vary depending on the load configuration and battery charge.
Table 30. Battery
Internal Batteries EBMs
Rackmount
Configuration
7001000 VA models: 36 Vdc (3 12V, 9 Ah)
1500 VA models: 48 Vdc (4 12V, 9 Ah)
20003000 VA models: 72 Vdc (6 12V, 9 Ah)
PW9130N1000R-EBM2U: 36 Vdc (2 x 3 12V, 9 Ah)
PW9130N1500R-EBM2U: 48 Vdc (2 x 4 12V, 9 Ah)
PW9130N3000R-EBM2U: 72 Vdc (2 x 6 12V, 9
Ah)
Tower
Configuration
700 VA models: 24 Vdc (2 12V, 9 Ah)
1000 VA models: 36 Vdc (3 12V, 9 Ah)
1500 VA models: 48 Vdc (4 12V, 9 Ah)
20003000 VA models: 96 Vdc (8 12V, 9 Ah)
PW9130N1000T-EBM: 36 Vdc (2 x 3 12V, 9 Ah)
PW9130N1500T-EBM: 48 Vdc (2 x 4 12V, 9 Ah)
PW9130N3000T-EBM: 96 Vdc (2 x 8 12V, 9
Ah)
Fuses Not applicable (4) 30A/125 Vdc fuses per EBM
Type
Sealed, maintenance-free, valve-regulated, lead-acid,
with minimum 3-year float service life at 25C (77F)
Monitoring Advanced monitoring for earlier failure detection and warning
Recharge Time (to
90%)
Internal batteries: 3 hours
1 EBM: 9 hours; 2 EBMs: 15 hours; 3 EBMs: 21 hours; 4 EBMs: 27
hours
Battery Port External three-pole Anderson connector on UPS for connection to EBM
Table 29. Battery Runtimes (in Minutes) at 100% Load (Tower Models) PF0.7 (Continued)
Tower Models
Load (VA/Watts) Internal Batteries + 1 EBM + 2 EBMs + 3 EBMs + 4 EBMs
