6. Function blocks
6.2 Interrupt function blocks
Description Note
(DWord)
QV Elapsed actual time of delay set at PD
Assigning operands
You can assign the following operands to the function block outputs that are numeric
outputs:
Assigning operands Outputs
Constant x
Markers: MB, MD, MW x
Analog inputs IA x
Analog output QA x
Numeric output from another QV FB x
You can assign the following operands to the function block outputs that are bit outputs:
Assigning operands Bit outputs
Constant 0, constant 1 x
M – Markers x
SN - Output bit via NET (send) x
N - Network marker bit x
nN - NET station n marker x
LE - Output backlight x
Q - Bit output from another FB x
Parameter set
Description Note
Parameter display
+ Call enabled
Function block parameters and constants can be
edited on the device.
Edit interrupt routine Clicking on the button will open the interrupt
routine
Simulation possible
6.2.3.4 Other
Retention
The function block does not recognize retentive data.
The interrupt program does not have any retentive data.
Monitoring the interrupt load
In total, no more than 8 interrupt sources are allowed to be processed in a single pro-
gram. The valid interrupt sources are the IC, IE, IT interrupt function blocks and the CF,
CH, and CI high-speed counters that are directly connected to the device inputs. For
more information, please refer to → "CF - Frequency counter", page 224, → "CH - High-
speed counter", page 230 , → "CI - Incremental counter", page 237 as well.
