34008235EN/AC - Page 18
5. Maintenance
Mounting the new battery module
Carry out the above instructions in reverse order.
5.4 Training centre
D - Pull the plastic tab to remove the
battery block and replace it.
◗ To ensure safety and high performance, use only batteries supplied by EATON.
◗ Take care to firmly press together the two parts of the connector during remounting.
To fully master operation of your EATON product and carry out level 1 servicing, see our complete range of technical
training courses, available in both French and English.
For further information, please visit our website: www.eaton.com
