3. Setting and Unsetting i-on16
Page 22
Remember to close the door.
c. Press the Exit Terminate Button.
The system sets.


Final Door Set:
a. Press .
The keypad sounds the exit tone
(an interrupted tone if the final exit
door is open, a continuous tone if
the exit door is closed). The top
line of the display shows the part
of the system being set, the
bottom line shows “Final Door
Set”.


b. Leave by the designated exit door.
c. Close the door.
The system sets.


Lock Set:
a. Press .
The keypad sounds the exit tone
(an interrupted tone if the final exit
door is open, a continuous tone if
the exit door is closed). The top
line of the display shows the part
of the system being set, the
bottom line shows “Lock Set”.


b. Leave by the designated exit door.
c. Close the door.
d. Lock the door.
