Table 25: PowerXL accessories
Type
Description Document
DX-KEY-LED2
DX-KEY-OLED
External keypad AP040022,
IL04012020Z
DX-NET-SWD1
Interface card for connecting to a SmartWire-DT network MN04012009Z,
IL04012025Z
DX-COM-STICK2
Parameter copying stick for establishing a Bluetooth
connection to PC software
MN040003,
IL04012021Z
DX-COM-PCKIT
Wired communication between variable frequency drive and
PC
MN040003,
IL04012022Z
DX-CBL-PC1M5
Wired communication between variable frequency drive and
PC
MN040003
DX-SPL-R145-2SL1PL
RJ45, 8-pin, splitter, 2 sockets, 1 plug on short connection
cable
lL04012023Z
DX-SPL-RJ45-3SL
RJ45, 8-pin, splitter, 3 sockets lL04012023Z
DX-SPL-RJ45 RJ45, 8-pin, splitter, 2 sockets, 1 plug IL 040026ZU
DX-SPL-RJ45-TERM RJ45, 8-pin, splitter, 1 socket, 1 plug, integrated bus
termination resistor for CANopen and Modbus
IL 040026ZU
drivesConnect
PC parameter configuration software for variable frequency
drives, with integrated oscilloscope function, drive control
function, and function block creation
MN040003
→
If you intend to use an external keypad and/or a parameter
copying stick with a DC1-…E1 variable frequency drive, please
note that only models DX-KEY-LED2 and DX-COM-STICK2 will
work.
DX-KEY-OLED can be used, but requires an update first.
