6 Parameter structure
6.1 Adjust parameters
DC1-S…20…, DC1-S…OE1 Variable Frequency Drives 05/21 MN040058EN www.eaton.com 121
6 Parameter structure
Table 28: Parameter Groups
Parameter P-14 is used to control access to the parameter groups:
• P-14 = P-37 (default setting: 101): enables access to the extended
parameter set (up to P-55 and up to P00-20)
• P-14 = P-37 + 100 (default setting: 201): enables access to the extended
parameter set for version 1 (up to P-68 and up to P00-50)
6.1 Adjust parameters
Table 29: Modify parameters
Parameter group
Value range Type Access right
Display values P00-01 - P00-20 DC1-S… ro
P00-21 - P00-50 DC1-S…E1 ro
Basis parameters P-01 – P-14 DC1-S… rw
Expansion P-15 – P-55 DC1-S… rw
Expansion, version 1 P-60 – P-68 DC1-S…E1 rw
Commands Description
Press the OK button and hold it down for two seconds in order to access the parameter interface.
→
The display will show the parameter that was last used.
Use the ▲ and ▼ buttons to select a parameter.
Press the OK button.
The value of the selected parameter can be changed.
Use the ▲ and ▼ buttons to change the parameter’s value.
Press the OK button to confirm the parameter value change.
As soon as the parameter is displayed, the value will have been saved.
Press the OK button and hold it down for two seconds in order to exit the parameter interface (display: "Stop").
