7 Technical Data
7.1 General rated operational data
DC1-S…20…, DC1-S…OE1 Variable Frequency Drives 05/21 MN040058EN www.eaton.com 157
7 Technical Data
7.1 General rated operational data
Technical data Symbol Unit Value
General
Standards EMC: EN 61800-3:2004+A1-2012
Safety: EN 61800-5-1
Degree of protection: EN 60529: 1992
Soiling: IEC 721-3-3
Certifications and manufacturer’s declarations on conformity CE, UL, cUL, UkrSEPRO, Gost-R
Production quality RoHS, ISO 9001
Climatic proofing ρ
w
% < 95 %, average relative humidity (RH),
non-condensing (EN 61800-5-1)
Ambient temperature
operation
IP20 (NEMA 0) ϑ °C -10 - +50 without derating
-10 - +45 for DC1-S1011… and DC1-S201…,
for UL compliance over a period of 24 hours
IP66 (NEMA 4X) ϑ °C -10 - +40 without derating
Hint:
Operation within a temperature range of 40 to 50 °C
does not conform to UL listing.
Storage ϑ °C -40 - +60 (frost-free and condensation-free)
Degree of pollution Non-conductive dust permissible
Transport Class 1C2 (chemical gases), Class 1S2 (solid particles)
Storage Class 2C2 (chemical gases), Class 2S2 (solid particles)
Operation Class 3C2 (chemical gases), Class 3S2 (solid particles)
Vibration level (not evaluated during operation)
Shock test
Pulse shape semi-sinusoidal
Top acceleration 15 g
Time Window 11 ms
Vibration test
Frequency range f Hz 10 - 150
10 - 57.55: 0.15 mm peak-peak
57.55 - 150: 1 g Top acceleration
Vibration evaluation 1 octave/minute
MTBF (mean time between failures) Years 157
Electrostatic discharge (ESD, EN 61000-4-2:2009 U kV ±4, contact discharge
±8, air discharge
Fast transient burst (EFT/B, EN 61000-4-4: 2004) U kV ±1, at 5 kHz, control signal terminal
±2, at 5 kHz, motor connection terminals,
Single-phase mains connection terminals
