Eaton PowerXL - Degree of Protection IP66

7 Technical Data
7.3 Dimensions
DC1-S…20…, DC1-S…OE1 Variable Frequency Drives 05/21 MN040058EN www.eaton.com 165
7.3.2 Degree of protection IP66
Figure 76: Dimensions for DC1-S… with IP66 degree of protection (NEMA 4X)
Table 51: Dimensions and weights DC1-S… in IP66
REV FWD
0
ON
OFF
PWR
b
a c
a1
c1
b1b2
a1
b1
⌀ 1
⌀ 2
a1
b1
FS Type a a1 b b1 b2 c c1 ⌀ 1 ⌀ 2 m
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
mm
(in)
kg
(lbs)
FS1 DC1-S17D0…
DC1-S24D3…
DC1-S27D0…
161
(6.34)
148.5
(5.85)
232
(9.13)
189
(7.44)
25
(0.98)
184
(7.24)
3.5
(0.14)
4
(0.15)
8
(0.31)
2.8
(6.17)
FS2 DC1-S1011…
DC1-S2011…
188
(7.4)
176
(6.93)
257
(10.12)
200
(7.87)
8
(1.1)
192
(7.56)
3.5
(0.14)
4.2
(0.16)
8.5
(0.33)
5
(11.02)
1 in = 1’’ = 25.4 mm, 1 mm = 0.0394 in
