1 Device series DC1-S…
1.4 Rated operational data
16 DC1-S…20…, DC1-S…OE1 Variable Frequency Drives 05/21 MN040058EN www.eaton.com
1.4.3.2 DC1-S2…device series
Mains voltage: 1 AC 220 - 240 V (±10 %), 50/60 Hz
Output voltage: 1 AC 220 - 240 V, 50/60 Hz
Type
Rated operational current Assigned Instance Motor Power Display (operating unit) Local controls Radio interference suppression filter Degree of protection Construction size Brake chopper
I
e
P
1)
(230 V,
50 Hz)
P
2)
(220 - 240 V,
60 Hz)
A kW HP
DC1-S24D3NN-A20CE1 4.3 0.37 0.5 LED – – IP20 FS1 –
DC1-S24D3FN-A20CE1 4.3 0.37 0.5 LED – ✓ IP20 FS1 –
DC1-S24D3NN-A66CE1 4.3
3)
0.37 0.5 LED – – IP66 FS1 –
DC1-S24D3FN-A66CE1 4.3
3)
0.37 0.5 LED – ✓ IP66 FS1 –
DC1-S24D3NN-A6SCE1 4.3
3)
0.37 0.5 LED ✓ – IP66 FS1 –
DC1-S24D3FN-A6SCE1 4.3
3)
0.37 0.5 LED ✓ ✓ IP66 FS1 –
DC1-S27D0NN-A20CE1 7 0.75 1 LED – – IP20 FS1 –
DC1-S27D0FN-A20CE1 7 0.75 1 LED – ✓ IP20 FS1 –
DC1-S27D0NN-A66CE1 7
3)
0.75 1 LED – – IP66 FS1 –
DC1-S27D0FN-A66CE1 7
3)
0.75 1 LED – ✓ IP66 FS1 –
DC1-S27D0NN-A6SCE1 7
3)
0.75 1 LED ✓ – IP66 FS1 –
DC1-S27D0FN-A6SCE1
7
3)
0.75 1 LED ✓ ✓ IP66 FS1 –
DC1-S2011NB-A20CE1
10.5 1.1 1.5 LED – – IP20 FS2 ✓
DC1-S2011FB-A20CE1
10.5 1.1 1.5 LED – ✓ IP20 FS2 ✓
DC1-S2011NB-A66CE1
10.5
3)
1.1 1.5 LED – – IP66 FS2 ✓
DC1-S2011FB-A66CE1 10.5
3)
1.1 1.5 LED – ✓ IP66 FS2 ✓
DC1-S2011NB-A6SCE1 10.5
3)
1.1 1.5 LED ✓ – IP66 FS2 ✓
DC1-S2011FB-A6SCE1 10.5
3)
1.1 1.5 LED ✓ ✓ IP66 FS2 ✓
1) As per IEC standards
2) As per UL 61800-5-1, Table DVE.1, March 6, 2015
3) Rated operational current at switching frequencies of up to 8 kHz and ambient temperatures of up to +40 °C
