31
Configuration
© 2013 EBS
Note:
The following parameters: analyzer name, analyze address, port relate to
settings of OSM.2007 receiver of monitoring system. Remote programming is
available only if above mentioned device (or software) is used.
9.2.2.5.2.2 CSD linking
Activate file in Main Menu and select Connection function (or after clicking on
icon on fast access bar) and click on GSM Modem tab to carry out configuration of this
mode.
On screen the window shall appear where it is possible to define:
Name of connection e.g. Remote CSD
Serial port where GSM modem is connected (e.g. Wavecom Fastrack)
PIN code of SIM card installed in GSM modem e.g. 1111
Serial port parameters: amount of bytes/sec. (e.g. 115200), data bytes (8),
parity (none), stop bits (1)
optional phone number of the SIM card installed in the modem
Click [Add] button to confirm settings and save connection (settings are inserted into
table). Since that time a remote connection to device, reading and saving of
parameters in Active Track memory is possible.
Note:
Remote configuration with CSD canal is possible if option of CSD data sending
has been activated both for SIM card inserted into a device and SIM card installed in
GSM modem. Beside, Active Track transmitter must enable to pick up data calls (see
GSM modems authorized phones)
Programming with CSD is also possible if OSM.2007 system has been installed, and
minimum one GSM modem is connected. If device has been entered onto server list
(factory number and SIM card telephone number –See OSM.2007 Operation Manual)
it is possible to use link via OSM. It is possible if device is not connected to the
