Active Track (beta version)
© 2013 EBS
device. For procedure refer to chapter Device programming .
e) Click [Start] button to start software exchange.
f) Loading course is displayed on special window.
g) Close the window after completed saving
From this time on the device will work under control of new firmware.
Note:
The above procedure shall be carry out with due care to avoid
improper device operation.
9.2.4 Device programming
Programming of device is possible with “GPRS transmitters configurator” configuration
program described in chapter Configuration program . To program the device
establish connection with a device.
Depending on connection mode there are two ways for programming.
9.2.4.1 Programming adapter and cable
In order to gain access to device's programming functions via RS232 port special
programming adapter (AGP3) and cable (LX-PROG or LX-DATA) is necessary. Adapter
is equipped with two connectors: PROG and MODEM. The first one is used for local
programming, controlling device's state (Device Monitor) and reading device's event
history. The second connector may be used for GSM modem work auditing.
Below is a summary of AGP3 adapter and cables application:
9.2.4.2 Local programming
To program a device locally follow the procedure:
a) Turn the device upside down, open lid by unscrewing bolts and take it off.
Remove battery from cavity (don't disconnect it!) and fasten AGP3 adapter in a
socket located near SIM card holder.
b) Connect PROG joint (on AGP3 adapter) with COM computer port by way of
service wire, defined in option Connections -> RS-232.
c) After connection and detection of programming wire a module shall signal this
