IGNITION SYSTEM
CS-600
14
3 IGNITION SYSTEM
(A)
(B)
(C)
(D)
(E)
(G)
(H)
(F)
(A) Flywheel (F) Spark plug cap
(B) Ignition coil (G) Switch lead
(C) Spark plug (H) Ground lead
(D) Cap cover (I) Ignition switch
(E) Spark plug cap coil
(I)
