60
Various Settings
What happens if an incorrect CD is
inserted?
"HELP" will be displayed for 5
seconds. Then the serial number will
be displayed.
"SEC" will be displayed for two
seconds. Then the six digit rolling code
will be displayed.
"DISC" flashes on the display.
You will have five more attempts to
insert correct disc.
The front panel opens.
"OK" is shown for two seconds and
then "Eject DATA DISC" is shown.
Eject the disc from tray, and manually
close the front panel.
ATTENTION
• If an incorrect CD is inserted, "ERR_"
("ERR" and error count) message will
appear for two seconds. Then, "Eject DATA
DISC" is shown. Eject the disc from tray.
• This process cancels the protection for ESN
main unit.
NOTE
If after 5 tries the correct Key CD is not
inserted, the display reads "CALL".
Contact ECLIPSE for assistance.
How to turn the security
indicator on/off
Once ESN security is activated, the indicator
flashes whenever the vehicle's ignition switch is
turned off, warning potential thieves that the main
unit is protected. However, if do not want this
visible deterrent, it may be turned off.
"IND. FLASH" means the security
indicator will flash when the vehicle's
ignition switch is off, and "IND.-----"
means it will not. Repeat the above
steps to reactivate the flash mode.
1
After the 5th incorrect attempt, the
"HELP" message will be displayed
for five seconds.
2
Eject the disc from tray, and
manually close the front panel.
3
While pressing button [6], press
the [SCREEN/TEXT] button, and
hold both for five seconds.
4
Press the [SCREEN/TEXT] button.
5
Press the [ (OPEN)] button.
6
Insert the Key CD into the disc slot.
It is easy to forget the name of your
Key CD. Make a note of the album
name to remind yourself (refer to page
112).
1
When the main unit is in the
standby state (with the power
turned off), continue to press both
[2] and [SCREEN/TEXT] buttons for
more than one second.
2
The "IND. FLASH" message or the
"IND.-----" message appears on the
display.
To Next Page
