ESN security operating procedure
41
VIII
After the [SEC] message will appear
for two seconds, rolling code (six digit)
will appear.
[DISC] flashes on the display.
You will have five more attempts to
insert correct disc.
If the correct CD is inserted, an [OK]
message will appear for two seconds
and the CD will be ejected.
ATTENTION
• If an incorrect CD is inserted, an [ERR_ ]
("ERR" and error number) message will
appear for two seconds, after which the CD
will be ejected.
• This process cancels the protection for ESN
main unit.
How to turn the security
indicator on/off
Once ESN security is activated, the indicator
flashes whenever the vehicle's ignition switch is
turned off, warning potential thieves that the main
unit is protected. However, if do not want this
visible deterrent, it may be turned off.
[IND. FLASH] means the security
indicator will flash when the vehicle's
ignition switch is off, and [IND.-----]
means it will not. Repeat the above
steps to reactivate the flash mode.
How to read the Electronic
Serial Number
[ESN] appears on the display, followed
by an eight-digit number; this number
is your electronic serial number (ESN).
You may use this number to identify
your Eclipse CD7100 in the event of
theft recovery.
3
Press the button [6], then
[SCREEN] button, and hold them
for five seconds.
4
Press the [SCREEN] button.
5
Insert the Key CD into the slot.
● Note ●
If after 5 tries the correct Key CD is not
inserted, the display reads [CALL]; the
main unit must be returned to Eclipse
to be reset. In this case, please
contact your Eclipse dealer for
assistance.
Your Key CD can be easily forgotten.
Write the album name in a reminder
note (See page 98).
1
With the main unit in standby,
press the button [2], then
[SCREEN] button and hold both for
more than one second.
2
[IND. FLASH] or [IND.-----] appears
on the display.
1
Check that the main unit is in
standby.
2
Press and hold the button [4], then
[SCREEN] button, and hold both
for more than one second.
To Next Page
