56
Various Settings
Selecting an equalizer mode
from memory
Press a preset button to select the equalizer
mode set in memory for the button. The buttons
that set equalizer modes in memory are called
preset buttons.
The preset pattern stored in memory
will be retrieved.
ATTENTION
When the preset value is changed, the display
shows as follows:
Measuring/display frequency
characteristic
Frequency characteristics inside the vehicle can
be measured and displayed on the display. The
measurement result can be referred to when
adjusting parametric equalizer. This result is also
necessary to automatically correct parametric
equalizer setting using E-iSERV Audio
Customize.
ATTENTION
• Adjust time alignment (see page 58) and
crossover (see page 58) before measuring
frequency characteristics.
• When measuring frequency characteristics,
CSII and Loudness settings are
automatically canceled.
• Close all doors and windows while
measurement is in progress.
Align the microphone with the actual
ear position and attach it to the
headrest or other appropriate fixture.
(Attach the microphone using tape or
string.)
1
Select any button, from [1] to [5],
and press it for less than one
second when PEQ setting mode is
activated.
P
1 to 5 (Preset ch No.)
CAUTION
In order to make measurement of frequency
characteristics easier, slight errors may occur
in the measurement data under some
circumstances when this function is used. In
addition, it is not equivalent to the precise
measurements that can be made by
specialist measuring devices.
1
Connect the optional microphone
(MEI-100) with a RCA connector to
the L-CH of the AUX jack of the
main unit.
To Next Page
