Eclipse CD7100 User Manual

How to operate the Sound Adjustment Mode
55
XI
When the 4-speaker layout is selected
When the 3 way speaker layout is selected
ATTENTION
It is not possible to set more than one band in
the same channel and median frequency.
Either change the median frequency of the
current band, or change the median frequency
of the another band.
The PEQ setting mode is activated.
Each time the button is pressed, the
band changes in the following order.
When the 4-speaker layout is selected:
1 → 2 → 3 → 4 → 5 → 6 → 7 → 1 → 
When the 3 way speaker layout is
selected:
Hi 1 → Hi 2 → Hi 3 → Hi 4 → Hi 5 →
Mid 1 → Mid 2 → Mid 3 → Mid 4 → Mid
5 → Low → Hi 1 → 
Upper: Increases level.
Lower: Decreases level.
Each time the button is pressed, the Q
curve changes.
WIDE ↔ Mid WIDE ↔ NORMAL ↔
Mid NARROW ↔ NARROW ↔
WIDE ↔ 
The preset value is overwritten by the
value set using the above steps.
The time alignment and crossover
adjustments will also be stored at this
time.
Band Adjustable frequency (Hz)
1 63, 80, 100
2 125, 160, 200
3 250, 315, 400, 500
4 630, 800, 1 k, 1.25 k
5 1.6 k, 2 k, 2.5 k, 3.15 k
6 4 k, 5 k, 6.3 k, 8 k
7 10 k, 12.5 k, 16 k
Channel Band Adjustable frequency (Hz)
Hi
Hi 1
200, 250, 315, 400, 500,
630, 800, 1 k, 1.25 k, 1.6 k,
2 k, 2.5 k, 3.15 k, 4 k, 5 k,
6.3 k, 8 k, 10 k, 12.5 k, 16 k
Hi 2
Hi 3
Hi 4
Hi 5
Mid
Mid 1
63, 80, 100, 125, 160, 200,
250, 315, 400, 500, 630,
800, 1 k, 1.25 k, 1.6 k, 2 k,
2.5 k, 3.15 k, 4 k, 5 k, 6.3 k,
8 k, 10 k, 12.5 k, 16 k
Mid 2
Mid 3
Mid 4
Mid 5
Low Low
20, 25, 31.5, 40, 50, 63, 80,
100, 125, 160, 200, 250
1
Press the [SELECT] (Upper/ Lower)
button to select the PEQ.
2
Press the [ENTER] button.
3
Press the [ENTER] button to select
the band to be adjusted.
4
Press the [SELECT] (Right/Left)
button to select the frequency to
be adjusted.
5
Press the [SELECT] (Upper/ Lower)
button for less than one second to
adjust the frequency level.
6
Press the [SELECT] (Upper/ Lower)
button for more than one second
to adjust the Q curve pattern.
7
Repeat the operations in steps 3 to
6 to change the settings for each
channel and band.
8
Hold down a button, [1] to [5], for
more than two seconds to preset a
value.
9
Press the [CUSTOM/MENU] or
[RTN] button to exit sound
adjustment mode.
