Eclipse CD7100 User Manual

How to operate the Sound Adjustment Mode
59
XI
The crossover setting mode is
activated.
Each time the button is pressed, the
channel changes in the following
order.
When the 4-speaker layout is selected:
Front → Rear → Woofer → Front → 
When the 3 way speaker layout is
selected:
HPF → Mid-LPF → Mid-HPF → LPF →
HPF → 
When the button is pressed, the
frequency changes in the following
order.
When the 4-speaker layout is selected:
Front/Rear:
63 Hz
↔ 80 Hz ↔ 100 Hz ↔ 125 Hz ↔
160 Hz
↔ 200 Hz ↔ 250 Hz ↔ 315 Hz
↔
400 Hz ↔ 500 Hz ↔ 630 Hz ↔
800 Hz ↔ 1kHz ↔ 1.25kHz ↔ 1.6 kHz
↔
2 kHz ↔ 2.5 kHz ↔ 3.15 kHz ↔
4kHz
↔ 5kHz ↔ 6.3 kHz ↔ 8kHz ↔
10 kHz
Woofer:
20 Hz
↔ 25 Hz ↔ 31.5 Hz ↔ 40 Hz ↔
50 Hz
↔ 63 Hz ↔ 80 Hz ↔ 100 Hz ↔
125 Hz
↔ 160Hz ↔ 200 Hz
When the 3 way speaker layout is
selected:
M-LPF/Hi:
200 Hz
↔ 250 Hz ↔ 315 Hz ↔ 400 Hz
↔
500 Hz ↔ 630 Hz ↔ 800 Hz ↔
1kHz
↔ 1.25kHz ↔ 1.6 kHz ↔ 2 kHz
↔
2.5 kHz ↔ 3.15 kHz ↔ 4kHz ↔
5kHz
↔ 6.3 kHz ↔ 8kHz ↔ 10 kHz
M-HPF/Low:
20 Hz
↔ 25 Hz ↔ 31.5 Hz ↔ 40 Hz
↔
50 Hz ↔ 63 Hz ↔ 80 Hz ↔ 100 Hz
↔
125 Hz ↔ 160Hz ↔ 200 Hz
The slope can be set to "Pass", "6dB/
oct", "12dB/oct", "18dB/oct" or "24dB/
oct".
Upper: The slope becomes more
gentle.
Lower: The slope becomes steeper.
2
Press the [ENTER] button.
3
Press the [ENTER] button to
crossover adjustment channel.
4
Press the [SELECT] (Right/Left)
button to select the cut-off
frequency.
5
Press the [SELECT] (Upper/ Lower)
button to set the slope.
6
Repeat the operations in steps 3 to
5 to change the settings for each
channel.
7
Press the [CUSTOM/MENU] or
[RTN] button to exit sound
adjustment mode.
