10.4 Configuration Parameters
Overview
Listed on the next pages are the identifying codes for the parameters in the various Set-up
Groups in this instrument. Most of the parameters are configurable through the hosts.
Some are Read Only and are indicated as such and cannot be changed.
Reading or Writing
Do a Read or Write, depending on your requirements, using the identifying code and
format code listed in the tables. The range or selection available for each range is listed in
the tables.
10.4.1 Lock
The identifying register addresses listed in Table 10-3 lists all the register addresses and
ranges or selections for the function parameters in Set-up Group Lock.
Table 10-3 Set-up Group Lock
Parameter
Description
Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Hex Decimal
Security Value 00 80 FP R/W
0 to 9999
Lockout 0084 132 INT R/W
0 = None
1 = Calibration
2=Configuration
3= Set Point
