Troubleshooting/Service

8/05 UDC2500 Universal Digital Limit ControllerProduct Manual 79

Procedure #1

Table 7-5 explains how to troubleshoot power failure symptoms.

Table 7-5 Troubleshooting Power Failure Symptoms

Step What to do How to do it

Check the AC line voltage. Use a voltmeter to measure the AC voltage

across terminals L1 and L2 on the rear

terminal panel of the controller.

Check the earth ground connection.

Make sure the chassis plugs

into the rear of the case

properly.

Withdraw the chassis and visually inspect the

controller board and the inside of the case.

Check the system for Brown-

outs, heavy load switching, etc.,

and conformance to installation

instructions.

Refer to

Section 2 - Installation.

Change Power board. Installation instructions supplied with new

board.
