3.4 Lock Set Up Group
Introduction
The Lock Set Up group contains the Function parameters that will allow your controller
to protect Configuration and Calibration data.
Because this group contains functions that have to do with Security and Lockout, it is
best to configure this group last, after all the other configuration data has been loaded.
Function Prompts
Table 3-4 LOCK Group Function Prompts
Function Prompt
Lower Display
Selection or Range of Setting
Upper Display
Parameter
Definition
SECUR
0 to 4095 When “LOCK” is configured as “NONE”, the
Security Code number is displayed and can
be changed using the raise/lower keys
LOCK
NONE
CAL
CONF
+SP
NONE – all parameters are read/write
CAL - all parameters are read/write except
Calibration
CONF – configuration parameters are Read
Only; no writes permitted
+SP – Only the Lockout group is available for
read/write. Setpoint value is Read Only.
