104 UDC2500 Universal Digital Limit ControllerProduct Manual 8/05
10.4.4 Options
Table 10-7 lists all the register addresses and ranges or selections for the function
parameters in Set-up Group Options.
Table 10-6 Set-up Group – Options
Parameter
Description
Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Hex Decimal
Auxiliary
Output
009E 158 INT R/W
0 = None
1 = Not Used
2 = Not Used
3 = PV
Low Scaling
Factor
0031 049 FP R/W Within the range of the
selected variable in ID 134
158
High Scaling
Factor
0032 050 FP R/W Within the range of the
selected variable in ID 134
158
Auxiliary
Output Range
00EC 236 INT R/W
0 = 4-20 mA
1 = 0-20 mA
Digital Input
#1 (External
Reset)
00BA 186 INT R/W
0 = None
1 = Enable
2 = External Reset Only
