Modbus Read, Write and Override Parameters plus Exception Codes
8/05 UDC2500 Universal Digital Limit ControllerProduct Manual 103
Parameter
Description
Register
Address
Data
Type
Access Data Range or
Enumerated Selection
Hex Decimal
Input 1
Transmitter
Characterization
00A9 169 INT R/W
0 = B TC
1 = E TC H
2 = E TC L
3 = J TC H
4 = J TC M
5 = J TC L
6 = K TC H
7 = K TC M
8 = K TC L
9 = NNM H
10 = NNM L
11 = Nicrosil H TC
12 = Nicrosil L TC
13 = R TC
14 = S TC
15 = T TC H
16 = T TC L
17 = W TC H
18 = W TC L
19 = 100 PT RTD
20 = 100 PT LO RTD
21 = 200 PT RTD
22 = 500 PT RTD
23 = Radiamatic RH
24 = Radiamatic RI
25 = Linear
26 = Square Root
Input 1 High
Range Value
001D 029 FP R/W –999. to 9999. Engineering
Units (Linear types only)
Input 1 Low
Range Value
001E 030 FP R/W –999 to 9999. Engineering
Units (Linear types only)
Input 1 Ratio 006A 106 FP R/W –10.00 to 10.00
Input 1 Bias 0069 105 FP R/W -10 to 10
Input 1 Filter 002A 042 FP R/W 0 to 120 seconds
Burnout (Open
Circuit
Detection)
0085 133 INT R 0 = Downscale
1 = Upscale
Emissivity 0017 023 FP R/W 0.01 to 1.00
