Eclipse UDC2500 Limit - Table 5-10 Restore Input Factory Calibration

Input Calibration
8/05 UDC2500 Universal Digital Limit ControllerProduct Manual 65
ATTENTION
A restored factory calibration overwrites any previous field calibration done for the input and
may change the High and Low Range Limits.
Protect your field calibration from accidental overwrites by configuring the appropriate
LOCKOUT selection after calibration.
See the Section 3 - Configuration for specific instructions to set the lockout.
Table 5-10 Restore Input Factory Calibration
Step Operation Press Result
1
Set LOCKOUT to
NONE
SetupSetup
until you see:
Upper Display
= SET UP
Lower Display = LOCK
FunctionFunctionFunction
Until you see:
Upper Display = one of the following:
NONE – all parameters are read/write
CAL – all parameters are read/write except Calibration
CONF – configuration parameters are Read Only; no writes
permitted
Lower Display = LOCK
or
Until NONE is in the upper display
2
Enter INPUT 1
Setup Group
SetupSetup
until you see:
Upper Display
= SET UP
Lower Display = INPUT 1
FunctionFunctionFunction
until you see:
Upper Display = the current selection
Lower Display = IN1TYP
or
to change the current selection to another selection
3
Scroll through
Functions
FunctionFunctionFunction
until the lower display rolls through the rest of the functions and
returns to:
Upper Display = the new selection
Lower Display = INxTYP
or
until you change the input selection in the upper display back to the
proper selection. You will see:
Upper Display = Original Input Selection that matches your
type of sensor.
Lower Display = INxTYP
4
Return to Normal
Operation
Lower
Display
Lower
Display
Lower
Display
to return to Normal operating mode.
The factory calibration will be restored.
