Configuration
8/05 UDC2500 Universal Digital Limit ControllerProduct Manual 31
3.6 Input 1 Set Up Group
Introduction
This data deals with various parameters required to configure Input 1.
Function Prompts
Table 3-6 INPUT 1 Group Function Prompts
Function Prompt
Lower Display
Selection or Range of Setting
Upper Display
Parameter
Definition
IN1TYP
B
E H
E L
J H
J M
J L
K H
K M
K L
NNMH
NNML
NICH
NICL
R
S
T H
T L
W H
W L
100H
100L
200
500
RADH
RADI
0-20
4-20
10m
50m
100m
0-5
1-5
0-10
TDIF
INPUT 1 ACTUATION TYPE – This
selection determines what actuation you are
going to use for Input 1.
B—B Thermocouple
E H—E Thermocouple High
E L—E Thermocouple Low
J H—J Thermocouple High
J M—J Thermocouple Med
J L—J Thermocouple Low
K H—K Thermocouple High
K M—K Thermocouple Med
K L—K Thermocouple Low
NNMH—Ni-Ni-Moly Thermocouple High
NNML—Ni-Ni-Moly Thermocouple Low
NICH—Nicrosil-Nisil Thermocouple High
NICL—Nicrosil-Nisil Thermocouple Low
R—R Thermocouple
S—S Thermocouple
T H—T Thermocouple High
T L—T Thermocouple Low
W H—W5W26 Thermocouple High
W L—W5W26 Thermocouple Low
100H—100 Ohm RTD High
100L—100 Ohm RTD Low
200—200 Ohm RTD
500—500 Ohm RTD
RADH—Radiamatic RH
RADI—Radiamatic RI
0-20—0 to 20 Milliamperes *
4-20—4 to 20 Milliamperes *
10m—0 to 10 Millivolts *
50m—0 to 50 Millivolts *
100m—0 to 100 Millivolts *
0-5—0 to 5 Volts *
1-5—1 to 5 Volts *
0-10—0 to 10 Volts *
TDIF—Thermocouple Differential *
* These input types are not available on
FM Models.
