Ecolab Ecoplus EXN-II User Manual

Rinse aid - SETUP 113
The following rinse aid must be configured for the use of the Ecoplus EXN-II:
- Liquid product via pump
(when using EcoPlus EXN)
The flow rate is set directly on the rinse aid pump used.
Release signals - SETUP 114
The ‘Enable Signals Setup
’ screen (114) is used to configure enable signals that are sent
from dishwasher modules to the controller PCB.
If enable signals are configured, the Ecoplus EXN-II waits until the
corresponding enable signal is present to deliver the metered quantity
.
You can configure the following sharing signals:
- Pre-dose
- Wash
- Rinse
If no input is activated, the corresponding dosage starts as soon as the voltage
is applied.
Start-up
36MAN054003, Ver. 1-02.2024
