5.1 Assembling the Ecoplus EXN-II
Personnel:
n
Mechanic
n
Specialist
NOTICE!
Mount the control unit at an easily accessible, frost-protected location.
Ä ‘Ambient conditions’ on page 56
1. Install the mounting plate as follows:
n With the included screws and dowels on a suitable wall.
or
n With the supplied set of threaded screws in a suitable place on the dishwasher
.
Ä Chapter 3 ‘Delivery’ on page 20
2. Ecoplus EXN-II
hang onto the mounting plate from above.
To remove the Ecoplus EXN-II, pull it upwards out of the mounting plate.
