11 Technical data
General
Data Value Unit
Supply voltage:
(standard unit, no transformer)
24 V DC
Supply voltage:
(unit with transformer)
230 V AC
Connection output (standard unit with transformer)
30 W
PCB power input
Max. 5 W
Protection class:
IP65
Protection class:
(standard unit, no transformer)
III
Protection class:
(unit with transformer)
II
Real-time clock
With battery back-up
(service life > 10 years)
Data interface
USB, RS485
Dimensions (H x W x D):
160 x 210 x 120 mm
Weight:
approx. 3.3 Kg
Inputs and outputs
Data Value Unit
Inputs:
Inductive conductivity measuring cell with integrated water tank
temperature sensor
Conductive conductivity measuring cell
Detergent/capsule switch empty signal input
24 VDC; I
IN
= 8 mA
Rinse aid empty signal input
24 VDC; I
IN
= 8 mA
"Detergent pre-dosing" release signal
24 VDC; I
IN
= 8 mA
"Detergent post-dosing" release signal
24 VDC; I
IN
= 8 mA
"Rinse aid dosing" release signal
24 VDC; I
IN
= 8 mA
"IN4" release signal
24 VDC; I
IN
= 8 mA
Outputs:
Detergent dosing (OUT1)
24 VDC
Rinse aid dosing (OUT2)
24 VDC
Alarm output (OUT3)
24 VDC
Max. load capacity*
Each output 1.5, total
(all 3 outputs): 1,5
A
*) The total output capacity must not exceed the total transformer capacity.
Technical data
55 MAN054003, Ver. 1-02.2024
