Ecom ST - 1.3 Keypad

ecom-ST 1.0 9
1.3 Keypad
1
Connection LED
(only by wireless
connection)
5
ESC key
(quit/escape menu)
9
Store key
2
Info LED (for
indication of
instrument status)
6
Digital flow indi-
cation/flow meter
10
Info key (access to
control menu)
3
Battery LED (for
indication of
charging status)
7
Enter key (confirm
selection)
11
ON/OFF key
4
Function keys
(assignment shown
on display)
8
Cursor control
(up/down/right/left)
10
8
5
6
1
2
7
3
9
11
4
In input mode, the numerical function of the keys is used to enter
figures.
